A premium 450–460W N-type bifacial curved solar panel with double glass and full-screen design — engineered for BIPV, curved rooftops, carports, and architectural installations where aesthetics and performance must coexist.
B-Type Curved Glass
The DHN-48Z16-DG-FS features a B-type curved glass structure where both the front and rear tempered glass panels are precision-bent to a consistent radius of curvature. This allows the module to conform to curved rooftops, barrel vaults, carport canopies, and architectural facades without the mechanical stress or efficiency loss associated with flexible thin-film alternatives. The double glass (DG) construction eliminates the need for a back sheet, providing superior moisture resistance and a design life exceeding 30 years.
Full-Screen Frameless
The full-screen (FS) frameless design removes the conventional aluminium frame, presenting a seamless all-glass surface that integrates naturally into modern building envelopes. The absence of a frame eliminates potential corrosion points, reduces soiling accumulation at the edges, and allows the module to be installed flush with surrounding surfaces. The clean aesthetic makes the DHN-48Z16-DG-FS the preferred choice for architects and building owners who require solar generation without compromising visual design.
N-Type 16-Wire
The 48-cell N-type monocrystalline bifacial configuration with 16 ultra-thin wires (Z16) delivers up to 21.0% module efficiency at 460W. N-type cells provide inherently lower light-induced degradation (LID) and better performance at elevated temperatures (Pmax coefficient −0.29%/°C) compared to P-type PERC. The bifacial design captures rear-side reflected irradiance, adding 5–15% additional energy yield in suitable installations — particularly effective on curved surfaces that naturally redirect light toward the module rear.
BIPV Ready
The DHN-48Z16-DG-FS is purpose-built for building-integrated photovoltaics (BIPV) applications: curved rooftops, skylights, canopies, carports, and facade cladding. The frameless double glass construction meets building material standards for structural glazing, and the module can serve as both a weather barrier and a power generator — replacing conventional roofing or cladding materials. Custom curvature radii and dimensions are available for large architectural projects, enabling seamless integration into bespoke building designs.
All electrical parameters measured at Standard Test Conditions (STC): irradiance 1,000 W/m², cell temperature 25°C, AM 1.5G spectrum.
| Parameter | DHN-48Z16-DG-FS-450W | DHN-48Z16-DG-FS-455W | DHN-48Z16-DG-FS-460W |
|---|---|---|---|
| STC Electrical Parameters | |||
| Rated Power (Pmax) | 450 W | 455 W | 460 W |
| Module Efficiency | 20.77% | 20.99% | 21.22% |
| Open Circuit Voltage (Voc) | 44.20 V | 44.35 V | 44.50 V |
| Short Circuit Current (Isc) | 13.05 A | 13.10 A | 13.15 A |
| Max Power Voltage (Vmp) | 37.20 V | 37.35 V | 37.50 V |
| Max Power Current (Imp) | 12.10 A | 12.18 A | 12.27 A |
| NOCT Electrical Parameters (800 W/m², 20°C, AM 1.5G) | |||
| Rated Power (Pmax) | 336 W | 340 W | 344 W |
| Open Circuit Voltage (Voc) | 42.00 V | 42.15 V | 42.30 V |
| Short Circuit Current (Isc) | 10.18 A | 10.22 A | 10.26 A |
| Temperature Coefficients | |||
| Pmax (α) | −0.29% / °C | ||
| Voc (β) | −0.25% / °C | ||
| Isc (γ) | +0.048% / °C | ||
| NOCT | 43 ± 2 °C | ||
| Mechanical Parameters | |||
| Cell Type | N-Type Monocrystalline, Bifacial, 16-Wire | ||
| Cell Configuration | 48 cells (Z16 — 16 ultra-thin wires) | ||
| Glass Type | B-Type Curved Double Glass (DG) | ||
| Frame | Frameless (FS — Full-Screen) | ||
| Front Glass | Curved tempered anti-reflective glass | ||
| Back Glass | Curved tempered glass (bifacial) | ||
| Junction Box | IP68, 3 bypass diodes | ||
| Cable & Connector | 4mm² cable, MC4 compatible | ||
| Ratings & Certifications | |||
| Max System Voltage | 1,500 V DC | ||
| Max Series Fuse Rating | 20 A | ||
| Wind Load | 2,400 Pa | ||
| Snow Load | 5,400 Pa | ||
| Operating Temperature | −40°C ~ +85°C | ||
| Certifications | IEC 61215 / IEC 61730 / CE / TÜV / BIPV | ||
| Product Warranty | 12 Years | ||
| Power Warranty | 30 Years linear (≥ 87.4% at year 30) | ||
| Tolerance: 0 / +5W | Bifacial gain: 5–15% additional rear-side yield | Custom curvature available on request | |||
Precision-bent front and rear tempered glass conforms to curved rooftops, barrel vaults, and canopies without mechanical stress or efficiency loss.
No aluminium frame — seamless all-glass surface integrates naturally into building envelopes, reduces edge soiling, and eliminates corrosion points.
DG construction replaces the back sheet with tempered glass, providing superior moisture resistance, fire rating, and a design life exceeding 30 years.
N-type cells deliver ≤ 1% first-year and ≤ 0.4%/year degradation — significantly better than P-type PERC, maximising lifetime energy yield.
Meets building material standards for structural glazing — the module acts as both weather barrier and power generator, replacing conventional roofing or cladding.
Best-in-class temperature coefficient means less power loss on hot days, delivering more energy in warm climates compared to standard P-type modules.
